LX-8820D UL94 Type Vertical and Horizintal Wire and Cable Flame Tester
◎Test Standard
UL94、GB / T2408-1996.
◎Products features
Flame tester is designed according to the relevant standard requirements of UL.
The Cable tester is composed by the test part and control part, using the integrated
design, to facilitate the installation at the scene and debug.
The shell of the test chamber and the important components are all manufactured by
stainless steel, resistant cigarettes and gas corrosion; The automatic degree of
control system is high, has automatic ignition function, temperature and time
figures show, so that the observation and records are facilitate and the use of
it is stable and reliable .
◎Product Specification
| Ignite Time | 0~99 min 99 sec adjustable |
| After flame time | 0~99 min 99 sec adjustable |
| Residual burn time | 0~99 min 99 sec adjustable |
| Burning angle | 20°,45°,90°(equal to 0°) canbe adjusted |
| Flame height | It can be adjusted from 20mm to 175mm according to the standard requirement |
| Burner size parameter | Nozzle diameter 9.5±0.3mm, nozzle effective length is 100±10mm, with air adjust hole. |
| Volume | 0.85 cubic meter |
| Notice | It is equipped with lighting device, air extracting device, gas flow regulating valve, product feature gas ,clamping etc . |
| Power supply | AC220V/50HZ |
