LX-8826A Convection and Ventilation Aging Oven （UL）
◎Product Details
◎This tester is designed to test rubber & plastic specimens of cord's insulator or jacket.
The tensile strength，elongation and hardness of dumbbell specimens before / after aging
can be compared .This tester uses hot-air-circulation to make specimens aging .Its interior
is sealed well and it is equipped with the induced draft device & auto shut-off protection if
over-heated .Inner air is changeable。Also can be used as a drying oven by introducing web-frame.
◎Product Specification
| Interior dimension | 40*40*55cm |
| Air-change rate | 3-250 Times/H(Adjustable) |
| Temp. controller | PIT digital setting |
| Temperature range | Ambient 300℃,Accuraacy ±1℃ |
| Heating power 5KW | 5KW |
| Set test time | 0.01S～999.9H |
| Watt-hour meter | 1-9999.9Wh |
| Specimen's rotary disk | 2 layers |
| Material | inner box：stainless steel inner box outer box：electrostatic electrostatic electorytic plate |
| Power | AC220V / 50Hz |
