LX-8808A Computer -control Pull-push Tester
◎Pull - Push Tester
The machine is suitable for different kinds of connector or plug ，It adopts LED mode to display maximum
insertion and extraction force and Current maximum force value .It has the function of auto zero, unit
conversion etc.With the design of rotating eccentric, it can reduce the manpower and improve the product
quality and receive high praise.
◎Specification
| Specimen Volume | 1 set |
| Load Cell | 0～50kg |
| Resolution offorce | 0.01kg |
| Transmission | Rotating eccentric |
| Sensing Method | High precision load cell |
| Display Items | 240*128 LCD |
| Number of Tests | 1 ~ 999999 Adjustable |
| The maximum teavel | 0-40 mm (adjustable ) long route can be customized |
| Data Storage | Storage 1000 data files |
| Range of speed | 0-70 times/min(optional) (LCD display) |
| Unit Conversion | N / KG |
| Report Printing | Micro printer(optional accessories) |
| Power supply | AC220V / 50Hz |
| Size of main machine | 500*450*550mm |
| Weight of main machine | 50Kg |
